ZCUT-100 heavy duty automatic tape dispenser is designed for high volume continuous industrial use applications. The cut width is up to 100 mm / 4 inch.
CUT WIDTH | CUT LENGTH | TAPE INNER DIAMETER | TAPE OUTER DIAMETER | VOLTAGE & POWER | DIMENSION & WEIGHT |
40~100 mm | 40~999 mm | 75mm | 130 mm | AC220V/110V & 180W | 262(W)*185(D)*330(H)mm& 11KG |
High speed: It can cut 100~120 cut per minute. (50mm long).
Tolerance: +/- 0.5% of cutting length.
Cutting type: Cutting is neat due to using a cold cutter which is durable.
Operation: Automatic and manual two kinds of mode switches.
Automatic stopper: It stops automatically if materials run out during operation.
Memory: Set-length, set quantity & set speed will not be erased even if power off & on.
Fit Tape: Adhesive tape, non-adhesive tape, protective film, alunium foil tape, cloth tape, etc.
Automatically dispenses and cuts virtually any tape – including duct tape.
Compact design and heavy duty metal construction.
Accepts tape widths from 40mm to 100mm.
Cut lengths from 1.6″ (40mm) to 394″ (9999mm).
Accuracy +/- .04″ (1mm) (dependant on type of tape).
Digital push switch display for easy length adjustments.
Comes with standard 3″ (76mm) core.
Adjustable feed intervals.
Safety interlock.
Can dispense some non-adhesive materials.
Four operating modes (Manual Feed / Manual Cut, Manual Feed & Cut, Auto Feed & Cut and Interval Feed & Cut).
Optional foot switch available, see Accessories.
Optional serrated cutting blade for thick tapes, P279S.
