AT-55 AUTOMATIC TAPE DISPENSER

AT-55 Automatic Tape Dispenser with 2 sensors are able to cut 2 tape rolls at a time. fit for cutting adhesive and non-adhesive tape, and have automatic feeding, automatic cutting function. For tapes with inner diameter 75mm and with finger safety protection.

Specifications

CUT WIDTH

CUT LENGTH

TAPE INNER DIAMETER

TAPE OUTER DIAMETER

VOLTAGE & POWER

DIMENSION & WEIGHT

7~50 mm

5~999 mm

75mm, 32mm, 25mm

180 mm

AC220V/110V & 18W

140(W)*157(D)*235(H)mm& 2.5KG

Fit Tape:  Adhesive tape & Non-adhesive tape

Applied tape: Transparent tape, mask tape, cloth tape, fibre tape and other tapes.

Application: Automotives, Electric & Electronics, Machinery & Hardware, Commodity, Beverage, Apparel, Medical, Chemical, Food, etc.

Features

  • Automatic cutting applied for various tapes within 55mm.

  • The cutting size can be 1mm as unit, and have automatic feeding, automatic cutting function.

  • Two rolls of transparent tape  with width less than 20mm  can be cut at the same time.

  • Matched ESD settings available.

  • If tape runs out, automatically shift to manual mode.

  • If the tape blocked, automatically shift to manual mode.

  • It can save the cutting size data evening power off.

  • Make sure of electronic sound and red indicator to alarm (electrify and abnormal working condition etc).
